Random white stroke on some borders when exported

[Mitch2024]

Attached are a couple of exports - see against dark background to see some side have what looks like 1px white stroke - totally random - can be on different sides.

Not in the design and a real pain.

Please add to bug list.

[Pšenda]

3 minutes ago, Mitch2024 said:

Not in the design and a real pain.

It is Pixel Perfect? - position and size is whole pixel?

[Hangman]

Hi @Mitch2024 and welcome to the forums,

1. Are you exporting your file to PDF?
2. Does your Affinity Document include Bleed?
3. Do the images and solid colour fills extend into the bleed area?

There is a known bug, with PDF exports, logged under AF-1340, where the exported size sometimes exceeds the document dimensions which can result in 1 px white borders... to avoid this add a 3 mm bleed to your source Affinity document and ensure any elements that run right to the page edges include bleed... this will negate the white borders on the exported PDF file...

[Mitch2024]

39 minutes ago, Pšenda said:

It is Pixel Perfect? - position and size is whole pixel?

Yes whole pixel retina.

[Mitch2024]

27 minutes ago, Hangman said:

Hi @Mitch2024 and welcome to the forums,

1. Are you exporting your file to PDF?
2. Does your Affinity Document include Bleed?
3. Do the images and solid colour fills extend into the bleed area?

There is a known bug, with PDF exports, logged under AF-1340, where the exported size sometimes exceeds the document dimensions which can result in 1 px white borders... to avoid this add a 3 mm bleed to your source Affinity document and ensure any elements that run right to the page edges include bleed... this will negate the white borders on the exported PDF file...

1. No these are for web so jpg

2. No bleed

3. colours and images extend well outside the artboard boundary

It sounds similar to the PDF bug - but on jpg - I have been working round by putting everything in a rectangular mask and exporting with a couple of pixels margin in PNG transparent - not ideal

[Hangman]

15 minutes ago, Mitch2024 said:

Yes whole pixel retina.

What are your document dimensions and the dimensions of the exported file?

[Mitch2024]

4 minutes ago, Hangman said:

What are your document dimensions and the dimensions of the exported file?

Ah - good question - I think you have solved it - artboard 1080 x 1350 px, but in Export persona has added 1px.

Manually correcting export persona size solves it.

I don't know if this is something I have done inadvertently or not - but seems random across multiple artboards and files.

[Hangman]

1 minute ago, Mitch2024 said:

I think you have solved it - artboard 1080 x 1350 px, but in Export persona has added 1px.

Is this also the case when you set the decimal places to six under the Affinity Designer User Interface Settings, i.e., does your Artboard still show integer values?

[Mitch2024]

7 minutes ago, Hangman said:

Is this also the case when you set the decimal places to six under the Affinity Designer User Interface Settings, i.e., does your Artboard still show integer values?

yes still showing integer values - but for new artboards consistent between design and export personas - so I should keep at 6 decimal places?

[Hangman]

4 minutes ago, Mitch2024 said:

for new artboards consistent between design and export personas - so I should keep at 6 decimal places?

That shouldn't be necessary... but while still showing six decimal places, check that the Artboard itself uses X and Y Integer values for the Artboard's position...

[Mitch2024]

12 minutes ago, Hangman said:

That shouldn't be necessary... but while still showing six decimal places, check that the Artboard itself uses X and Y Integer values for the Artboard's position...

current artboard X & Y are showing decimal places until I type in an integer, should I ensure integer only X & Y, H & W ?

[Hangman]

1 minute ago, Mitch2024 said:

current artboard X & Y are showing decimal places until I type in an integer, should I ensure integer only X & Y, H & W ?

Yes... doing so should ensure your exported JPEG is exactly 1080 x 1350 px...

[Mitch2024]

3 minutes ago, Hangman said:

Yes... doing so should ensure your exported JPEG is exactly 1080 x 1350 px...



perfectly illustrated - thank you for all your help on this

[Hangman]

Just now, Mitch2024 said:

perfectly illustrated - thank you for all your help on this

That's no problem at all, hopefully, you'll have perfectly exported JPEGs from now on...

[Pšenda]

1 hour ago, Mitch2024 said:

should I ensure integer only X & Y, H & W ?

Yes - only this is Pixel perfect.

3 hours ago, Pšenda said:

It is Pixel Perfect? - position and size is whole pixel?
