  1. unni

    Focus stacking with 95 images

    thanks @Kasper-V @John Rostron. the processing time per stack is about 30mts.as you mentioned, it leads to the final image as the output. there was an overall haze/lack of contrast which was rectified wonderfully by the dehaze feature of AP. the key to success is to have a setup which can move without axial errors. to achieve it professionally, we need linear guides which is expensive. i could achieve similar results with the heavy milling machine table and my crude dial! lighting diffuser is required to get even light and elimination of specular spots but with 1/128 power level and no diffusers, this image was fine, may be because wings are relatively a flat field case compared to other body parts which are more 3 dimensional.
  2. Focus stacking with AP. It took about 30 mts for each image. No cropping, only small trimming of borders. Minimal editing like enhancing contrast only done. Subject: a dead moth which I accidentally came across in the stairway. Magnification: The field of view for 5X objective is around 5mm X 3mm and 10X about 2.5mm X 1.5mm. From internet I see that the length of one scale is about 0.20mm and width at tip 0.035 mm and distance between the fine longitudinal lines on a scale about 0.001mm. So the smallest feature just visible is about 1 to 2 microns (0.001 to 0.002mm) and 5 micron features are clearly seen. Camera: Nikon D3100 with 5X and 10X Plan achromatic metallurgical finite objective. Lighting: One flash Godox TT600 triggered by hotshoe mounted wireless trigger Godox X1N. Powerlevel 1/128, no diffusers. step movement: Milling machine table , each step was about 15 microns, manual turning. More details of setup: https://forum.affinity.serif.com/index.php?/topic/70721-flame-of-the-woods/ 10X objective, 95 images stack( eyes) 5X objective, 47 images stack(hair and scales of wings) 10X Objective , 40 images stack(scales on wings)
  3. unni

    Feedback on Beta

    @atefoto Hello Aleksander, I have not used screen capture programs. So I am giving the process in steps. Sequence of processing: 1. Discarded two images which did not belong to the exposure bracket sequence. 2. Renamed the images as 1a to 1e, 2a to 2e, 3a to 3e. These are three sets of exposure bracketed images. 3. Each set seems to be taken with a large overlap of about 70%. Overlap of about 30% is sufficient. 4. Launch AP. 5. File>HDR Merge>Add> and select images 1a to 1e. Tick options Auto align, NR, Tone map. In the pop box, select perspective. 6. Save output as HDR1. 7. Repeat 5 above for the remaining two sets. 8. Now you have three images - HDR1, HDR2, HDR3. 9. File>New Panorama>Add. Now select the three images of 8 above. 10.Create the final panorama. I am not sure whether AP or photoshop can handle exposure bracketed panoramas or HDR. It will get confused and align the wrong images. This is the reason for the issues you noted. It is best to process each exposure bracket set separately and then make the panorama from the output of each set. Hope this helps ! Unni ------------------------------------------------------------------------------------------------------------------------------------------- Did you have to do something special to get them aligned? No, nothing special done. all default settings. For serious panoramas, it is better to have a nodally corrected setup.
  4. unni

    Feedback on Beta

    I downloaded the jpegs, made 3 sets of 5 images. Each set was put through HDR. This gave 3 images as output. The 3 HDR output images was treated in panorama mode to get the single final image. No other editing was done except slight exposure correction by curves at the right top quadrant area for clouds. The HDR processed within 3 minutes (per set of 5 jpegs). The second image is a quick hand manual exposure blending of just two images.
  5. Below is a final image exposure blended manually using luminosity masks, intermediate LAB mode usage, USM, clarity . One mid and one high exposure was used as input and aligned as stack, ungrouped, saved as two tif images, then opened the tif images as layers. Regular processing done on layers after this stage.(There is no pano step in the below image). Image taken with D7000, handheld, 70mm , f7.1, 1/2500, iso 320, Nikon 70-300 VRii lens. (The image is posted in beta forum of AP in windows. Link posted here)
  6. unni

    Feedback on Beta

    I tried the following steps: 1. Images 1 and 2 - top portion of scene low and mid exposure. 2. Images 3 and 4 - bottom portion of scene, low and mid exposure, 30% overlap with images 1 and 2. 3. Open as stack 1&2, align perspective only, ungroup stack and store in tif format as individual images. 4. Do the same 3rd step with images 3 and 4. 5. Now make pano using image 1 and 3 to get a low exposure image and save as A in tif. 6. Make pano using image 2 and 4 to get mid exposure image and save as B in tif. 7. Open image A and B as a stack, align using option scale,rotate,translate, then ungroup. 8. On checking the alignment by turning one layer ON and OFF at 600X or so does not show any misalignment. This shows that it is possible to make a final pano out of different sets of exposure bracketed images. If the images are shot with nodal correction brackets/tripod, step 7 may require only perspective option in the stack alignment. Below is a final image exposure blended manually using luminosity masks, intermediate LAB mode usage, USM, clarity . One mid and one high exposure was used as input and aligned as stack, ungrouped, saved as two tif images, then opened the tif images as layers. Regular processing done on layers after this stage.(There is no pano step in the below image). Image taken with D7000, handheld, 70mm , f7.1, 1/2500, iso 320, Nikon 70-300 VRii lens. @Chris B : My system is a normal core I3-4150 CPU, 3.5GHz, 16GB ram, 64bit Win 7, Gigabyte motherboard, home assembled.
  7. unni

    Feedback on Beta

    I do panos, stacking and ungrouping for subsequent manual blending, focus stacking of more than some 200 images but have not come across such a difficult situation as reported in above threads. I use hugin also for panos,it's good but found AP doing a better and faster job though hugin has more options and alignment related features being specifically for panos work. Editing features are minimal in hugin. Ishall try to do some trials to simulate reported issues and report if problems are noted.
  8. CS6 Two gradient layers, black left and white right. Top layer set to difference blend mode. Compared to AP, this gives symmetrical response and good adjustment range for the tonal width slider.
  9. I checked by having two gradient layers with the top one in difference mode. While changing the filter settings, effect is less for the highlights slider. It can be seen from the mild vertical grey area on the left side of the second image. In the gradient, full white is on the left side.
  10. unni

    violets and bee

    Camera: D3100 Nikon Lens: Tamron 90mm macro iso 100, f8, 1/125sec, Godox TT600 handheld external flash and X1T-N wireless remote on camera, 1/32 flash power. Camera Handheld. (Left hand flash and right hand camera with left hand fingers supporting camera lens barrel farthest end.) Processing: No settings modified in develop persona. After opening in photo persona, made color adjustments in LAB color space. Back in RGB space, made multiple curves adjustment targeting flower outer petals, inner white petals, greens and bee body. luminosity masks were used for the targeted adjustments. Flattened the layers, took it to LAB, used unsharp mask on lightness channel. Brought back to RGB color space, exported image to jpeg. Image below processed in AP. The second image is without any processing.
  11. unni

    Clipping Indicator Macro

    @αℓƒяє∂ @John Rostron : Thanks for the feedback on the afmacro extension. Browsed through the flag waving - interesting application !
  12. unni

    Haze removal

    This is in chennai city coast (India). These fishermen take enormous risks when they go out into the sea. When I saw their boats and trawlers, it was looking heavily used up and I think they customize the operational tools or other mechanisms related to their activity. I think the main share of the catch do not go to them . It will be going to the intermediate traders and other levels in the business chain. When they go out on rough sea days, they do not know whether they will be back. They earn on a daily basis, so no sail, no money. In july, there was a flood in Kerala state (India) which was happening after a 100 years. Around 35 dams were opened and overflowing ! State machinery and military was supporting the rescue but their modern boats could not go into all the flooded lanes of the city due to its design. During this time, similar fishermen from the neighboring towns and other districts took their boats and went all out for the rescue operations. It was just a spontaneous urge to save lives due to the confidence they have in working on rough waters.Their boats were powerful and could move through shallow waters. Operating round the clock, these guys saved several hundreds of lives. In the end, after a week or so, they returned to their homes. Many of their boats were unusable at the end of this operation and they refused to accept a single penny from the people they saved or from the government. What they said was that the honour given to them by the society was of highest value and they are satisfied by that. If you google on "kerala flood", similar news can be seen with details.
  13. unni

    Haze removal

    Hello john, The shot was at iso 100/f11/8sec/55mm/9am. So it was with ND1000. In the fishing harbour, by this time most of the vessels would return and the fish will be at the counters and auction houses. You can note the many boats lying still at the far end after offloading the day's catch. Activity on the harbour then shifts to working inside the boat for maintenance, etc. So I felt like making the water slow down and avoid the ripples, just to give the feel of lesser activity. Infact, the shot was not seriously composed, the thought of slowing down came in as a casual thought . The small boat was stationed there and I think they were doing something with the net. First I thought of removing the boat but then decided to leave it because without it, the shot would look too flat. I had the polariser but the light was too high for its ND property ( 1 stop, may be). I am yet to check the pol + ND combination though it is one of the mix that will be required for specific seascapes towards early/late twilight hours.
  14. unni

    Haze removal

    its with nikon d7000 and kit lens. i have used nd filter also. nd64 or nd1000, i dont remember. ND was used to get the water surface smooth.
  15. unni

    Haze removal

    Fishing harbour with haze removal,sharpening,clarity and some curves applied. Original unprocessed
×
